Non-Insulated Butt Connector Assortment Kit - 22-10 Gauge - 150 Pieces - Made in USA

Construct reliable, high-performance wire connections with this 150-piece non-insulated butt connector assortment kit. Designed for professional use, these terminals are manufactured from pure copper (Alloy 110), then annealed and electro tin-plated to ensure exceptional corrosion resistance and conductivity. The brazed barrel seams and "V" groove serrations provide maximum tensile strength after crimping—ideal for demanding electrical applications.

Specifications & Features

• Material: Pure copper (Alloy 110), annealed
• Plating: Electro tin-plated
• Insulation: Non-insulated
• Termination type: Crimp
• Seam type: Brazed barrel
• Serration design: "V" grooves for optimal contact and pull strength
• Operating temperature: up to 230°F
• Each terminal is clearly marked with its gauge size for quick identification
• Rated for up to 600 volts
• Complies with MIL-T-10727C Type 1 and ASTM B 545 B standards (tin plating thickness: .0001"–.00025")
• Certified to cULus safety standards
• Made in the USA

Kit Contents

• 50 – 12-10 Gauge Non-Insulated Butt Connectors (B1210)
• 50 – 16-14 Gauge Non-Insulated Butt Connectors (B1614)
• 50 – 22-18 Gauge Non-Insulated Butt Connectors (B2218)
