High Temperature Female Quick Disconnect Terminals - 22-18 AWG, 0.250" Tab - 100 Pack - Made in USA

These high-temperature female quick disconnect terminals are built for demanding electrical applications where extreme heat and reliability are critical. Made in the USA, each connector features a nickel-plated steel body and butted seam construction, rated for up to 900°F (482°C) and 600 volts. Designed for crimp termination with 22–18 AWG copper wire, and equipped with a 0.250" tab for broad compatibility.

Specifications & Features

• Wire Range: 22–18 AWG
• Tab Size: 0.250" (1/4")
• Temperature Rating: 482°C / 900°F
• Voltage Rating: 600V
• Material: Nickel-plated steel
• Insulation: Non-insulated, high-temp construction
• Termination Type: Crimp
• Connector Type: Female quick disconnect
• Profile: Low-profile for tight-space applications
• Engineered for use with copper wire only
• Corrosion-resistant and thermally stable under extreme conditions
• Manufactured in the United States
