14 AWG Fusible Link Wire - Universal Automotive Circuit Protection - 10 ft to 100 ft - Made in USA

This 14 AWG automotive fusible link wire provides essential overcurrent protection in high-amperage electrical systems. A fusible link functions like a slow-blow fuse—constructed from a short length of wire typically four AWG sizes smaller than the circuit it protects. For example, an 18 AWG fusible link may be used to protect a 14 AWG circuit. In the event of excessive current, the conductor melts, while its high-temperature, fire-resistant insulation contains sparks and heat to prevent electrical fires.

Specifications & Features

• Wire Size: 14 AWG
• Length: 10 ft coil
• Fit Type: Universal
• Color: Black
• Voltage Rating: 50V (low voltage wire)
• Temperature Rating: 150°C
• SAE Specification: SAE J-1128 Type HTS
• Insulation designed to contain heat and flame during wire melt events
• Commonly used in wire harnesses where standard fuses are not suitable
• Ideal for 12V and 24V automotive circuit protection
• Made in USA
